Sound and Lights

Key Features & Technology:

  • The T8 system features real-time robotic control of vertical and horizontal acoustic dispersion.

  • Its waveguide can be adjusted robotically, providing variable horizontal dispersion from 60 to 120 degrees.

  • This allows for precise, real-time control over the acoustic output, including vertical line source manipulation to a resolution of 0.1°.

  • The variable horizontal dispersion allows for tapered arrays customized for different venues.

  • The system incorporates advanced components such as 8-inch Tetracoil low-frequency transducers and a 3-inch dual ring radiating mid-frequency driver.

  • It also uses a two-channel VE15 1,400 W Class D amplifier.

  • Each module has integrated power electronics, network endpoints, DSP, and robotic actuators.

  • The system can be flown straight and then configured remotely, increasing safety and speed.

Benefits:

  • The system allows users to focus sound energy, maximizing clarity and minimizing unwanted reflections.

  • It reduces noise impact outside the main audience area.

  • The system offers flexibility for various venues and events.

  • Precise control and advanced components contribute to high-quality sound.

  • The system can be configured and flown by a single operator.

Technical Specs (Key Highlights):

  • Maximum SPL: 143.5 dB.

  • Frequency Response: 50 Hz - 20 kHz.

  • Horizontal Directivity: 60° - 120° (Robotic).

  • Vertical Adjustment: 0° - 12° (Robotic).

  • Vertical Resolution: 0.1° Increments.

  • Weight: 31.4 kg / 69.2 lb.

Note: While other line array systems exist (e.g., dBTechnologies DVA T8), the PK Sound T8 is distinguished by its robotic control features.

CHAUVET DJ SLIM PAR T12 BT Compact Wash LED (RGB) PAR all controllable by Bluetooth



PK Sound

Patrick Lamb Production team has been non-stop with events. We have warehouses of sound equipment, a finely tuned team, and a positive approach towards making your event sound great, fluid, and organized with google docs that we setup for all of our clients so that we are all in sync. We have done over 250 indoor and outdoor events over the last few years with the best audio equiptment that money can buy.

QSC 2000 Watt Monitors Or Mains
